AGICO Sale roll form machines, floor deck forming machinein China

MACHINE COMPONENTS:- Roll Form Machines,Floor Deck forming machine
(1) Manual Un-coiler 1 set
(2) Roll-Forming M/C 1 set
(3) Hydraulic Cutting 1 set
(4) PLC Control System 1 set
(5) Product Rack (un-powered) 1 set

TECHNICAL SPECIFICATION
(1) Manual Un-coiler:
Un-powered; Load capacity = Max.5Tons;
(2) Roll-Forming M/C:
About 18steps to form; Material of Roller: 45# steel with chromizing on surface
Voltage:380V/50Hz; Main line speed:8-12 m/min;
(3) Hydraulic Cutting:
Stop to cut, Post cut,
Cutting tool material: Cr12, Heat treatment
(4) PLC Control System:
Using Mitsubishi PLC Control the quantity, length automatically, LCD screen,
(5) Product Rack (UN powered)

Hydraulic Un-coiler:
Hydraulic system to expand coil inner hole;
Frequency Inverter to regulate turning speed,
Automatic stop device;Load capacity = Max.5Tons; MATERIAL:
(1) Coil Width: 1250mm
(2) Suitable Coil Thickness: 0.3-0.5mm
(3) Suitable Raw Materials: Pre-painted coil (Q235A); Yield bearing stress: 235 Mpa

AGICO is manufacture and supplier roll form machines, Door Frame , floor deck forming machine, rollforming machine, rollforming, roofing machinery in China.
